SPX FLOW Power Team RA556 55 Ton Aluminum Hydraulic Single Acting Cylinder/Ram, 6.13" Stroke, 10.75" Retracted, 16.88" Extended
SPX FLOW Power Team RA556 55 Ton Aluminum Hydraulic Single Acting Cylinder/Ram, 6.13" Stroke, 10.75" Retracted, 16.88" Extended
Order No. SPX-RA556
List Price: $2,175.97
Price: $2,079.14
Availability: In Stock

HALF THE WEIGHT OF EQUAL CAPACITY STEEL CYLINDERS.

  • Aluminum body resists sparking in explosive environments
  • Hard coated aluminum piston rod and cylinder bore resist wear and corrosion
  • Grooved piston top helps keep the load from sliding on top of piston
  • Designed for jacking and other non-production operations

Specifications

RETRACTED HEIGHT (IN. [MM])10.75 [273,1]
EXTENDED HEIGHT (IN. [MM])16.88 [428,6]
OUTSIDE DIAMETER (IN. [MM])5.25 [133,4]
BASE TO PORT (IN. [MM])1.38 [34,9]
PISTON ROD DIAMETER (IN. [MM])3.13 [79,4]
ROD PROTRUSION (IN. [MM])0.25 [6,4]
BORE DIAMETER (IN. [MM])3.75 [95,3]
CYLINDER CAPACITY (TONS)55
CYLINDER EFFECTIVE AREA (SQ. IN. [CM²]11.04 [71,2]
INTERNAL PRESSURE AT CAPACITY (PSI)9960
OIL CAPACITY (CU. IN. [CM³])67.60 [1.109,0]
STROKE (IN. [MM])6.13 [155,6]
TONS AT 10,000 PSI [METRIC TONS AT 700 BAR]55.20 [50,1]
WEIGHT (LBS. [KG])24.00 [10,9]

  • Weight:  24.00 lbs
