SPX FLOW Power Team C2514CBT Cylinder 25 Ton, Single Acting, 14-1/4" Stroke, Threaded End
SPX FLOW Power Team C2514CBT Cylinder 25 Ton, Single Acting, 14-1/4" Stroke, Threaded End
Order No. SPX-C2514CBT
List Price: $1,876.98
Price: $1,793.46
Availability: In Stock

RUGGED, HIGH QUALITY CYLINDER USED FOR LIFTING AND PRESSING.

  • Aluminum bronze bearing reduces wear caused by off-center loads.
  • Single-Acting, Spring-Return.
  • Maximum sized springs speed piston return and increase spring life.
  • Collar threads are standard on all C-Series models, simplifying fixturing applications.
  • Removable rubber boots protect collar threads during transport and storage.
  • Solid steel cylinder body for durability.
  • Chrome plated piston rod resists wear and corrosion.
  • Wide range of accessories available that mount onto the piston rod, collar, or base.
  • Base mounting holes standard on 5 through 55 ton cylinders and optional on 75 and 100 ton cylinders.
  • A 3/8" NPTF female half coupler is standard.
  • Complies with ANSI / ASME B30.1 Safety Standards.

Specifications

A - RETRACTED HEIGHT (IN. [MM])21.38 [542,9]
B - EXTENDED HEIGHT (IN. [MM])35.63 [904,9]
C - OUTSIDE DIAMETER (IN. [MM])3.38 [85,7]
D - COLLAR THREAD (IN.)3 5
E - PISTON COLLAR THREAD LENGTH (IN. [MM])1.94 [49,2]
F - BASE TO PORT (IN. [MM])1.88 [47,6]
H - PISTON ROD DIAMETER (IN. [MM])2.25 [57,2]
K - ROD PROTRUSION (IN. [MM])1.88 [47,6]
P - PISTON ROD THREAD (IN.)2–11.5
Q - INTERNAL BASE THREAD (NPSM)2–11.5
BORE DIAMETER (IN. [MM])2.56 [65,1]
CYLINDER CAPACITY (TONS)25
CYLINDER EFFECTIVE AREA (SQ. IN. [CM²]5.16 [33,3]
INTERNAL PRESSURE AT CAPACITY (PSI)9699
OIL CAPACITY (CU. IN. [CM³])73.50 [1.205,0]
STROKE (IN. [MM])14.25 [362,0]
TONS AT 10,000 PSI [METRIC TONS AT 700 BAR]25.80 [23,4]
WEIGHT (LBS. [KG])40.20 [18,2]

  • Weight:  40.20 lbs
