SPX FLOW Power Team RD256 25 Ton Hydraulic Double Acting Cylinder/Ram, 6.25" Stroke, 12.38" Retracted, 18.63" Extended
SPX FLOW Power Team RD256 25 Ton Hydraulic Double Acting Cylinder/Ram, 6.25" Stroke, 12.38" Retracted, 18.63" Extended
Order No. SPX-RD256
List Price: $2,185.00
Price: $2,087.76
Availability: In Stock

HIGH TONNAGE PREMIUM DESIGN FOR HIGH CYCLE LIFE.

  • Perfect for bridge lifting, building reconstruction, shipyard, utility and mining equipment maintenance
  • Aluminum bronze overlay bearings provide long life
  • Chrome plated piston rod resists corrosion
  • Load cap snaps out to expose internal piston rod threads for pulling applications; threads withstand full tonnage
  • Grooved ring pattern in load cap helps guard against load slippage
  • Each cylinder has two 9796 3/8” NPTF female half couplers
  • Built-in safety relief valve prevents over-pressurization of the retract circuit
  • Feature mounting holes and collar threads

Specifications

RETRACTED HEIGHT (IN. [MM])12.38 [314,3]
EXTENDED HEIGHT (IN. [MM])18.63 [473,1]
OUTSIDE DIAMETER (IN. [MM])4.00 [101,6]
COLLAR THREAD (IN.)4-12
PISTON COLLAR THREAD LENGTH (IN. [MM])1.63 [41,3]
BASE TO PORT (IN. [MM])1.00 [25,4]
CYLINDER TOP TO PORT (IN. [MM])2.50 [63,5]
PISTON ROD DIAMETER (IN. [MM])2.13 [54,0]
PISTON ROD INTERNAL THREAD AND DEPTH (IN.)1 1
ROD PROTRUSION (IN. [MM])0.38 [9,5]
BORE DIAMETER (IN. [MM])2.56 [65,1]
CYLINDER EFFECTIVE AREA - PULL (SQ. IN. [CM²]1.61 [10,4]
CYLINDER EFFECTIVE AREA - PUSH (SQ. IN. [CM²]5.15 [33,2]
CYLINDER CAPACITY - PULL (TONS)8
CYLINDER CAPACITY - PUSH (TONS)25
INTERNAL PRESSURE AT CAPACITY - PULL (PSI)9934
INTERNAL PRESSURE AT CAPACITY - PUSH (PSI)9695
LOAD CAPACITY DIAMETER (IN. [MM])2.13 [54,0]
OIL CAPACITY - PULL (CU. IN. [CM³])10.10 [166,0]
OIL CAPACITY - PUSH (CU. IN. [CM³])32.20 [528,0]
STROKE (IN. [MM])6.25 [158,8]
TONS AT 10,000 PSI - PULL [METRIC TONS AT 700 BAR]8.00 [7,3]
TONS AT 10,000 PSI - PUSH [METRIC TONS AT 700 BAR]25.80 [23,4]
WEIGHT (LBS. [KG])39.80 [18,1]

  • Weight:  39.80 lbs
