SPX FLOW Power Team RLS50 5 Ton Hydraulic Single Acting Low Profile Spring Return Cylinder, 9/16" Stroke
SPX FLOW Power Team RLS50 5 Ton Hydraulic Single Acting Low Profile Spring Return Cylinder, 9/16" Stroke
Order No. SPX-RLS50
List Price: $425.00
Price: $406.08
Availability: In Stock

IDEAL FOR CONFINED AREAS FROM 1-5/8” TO 4” CLEARANCE.

  • Cylinder body, piston and gland nut "Power Tech" treated for corrosion and abrasion resistance (see page 8)
  • Standard domed piston rod (5-30 ton) or swivel cap (50-150 ton) minimize effects of off-center loading
  • Unique heavy duty spring provides fast piston return
  • A 9796 3/8" NPTF female half coupler is standard with each cylinder (the RLS50 has a 3/8" coupler which is not angled). Oil ports are 3/8" NPTF.
  • Couplers on all cylinders, except RLS50, are angled upward for extra clearance

Specifications

RETRACTED HEIGHT (IN. [MM])1.63 [41,3]
EXTENDED HEIGHT (IN. [MM])2.19 [55,6]
OUTSIDE DIAMETER (IN. [MM])1.63 [41,3]
OUTSIDE DIAMETER (IN. [MM])2.56 [65,1]
BASE TO PORT (IN. [MM])0.75 [19,1]
PISTON ROD DIAMETER (IN. [MM])0.63 [15,9]
MOUNTING HOLE LOCATION (IN. [MM])0.75 [19,1]
MOUNTING HOLE LOCATION (IN. [MM])1.13 [28,6]
MOUNTING HOLE LOCATION (IN. [MM])0.25 [6,4]
MOUNTING HOLE LOCATION (IN. [MM])1.00 [25,4]
BORE DIAMETER (IN. [MM])1.13 [28,6]
CYLINDER CAPACITY (TONS)5
CYLINDER EFFECTIVE AREA (SQ. IN. [CM²]0.99 [6,4]
INTERNAL PRESSURE AT CAPACITY (PSI)10061
OIL CAPACITY (CU. IN. [CM³])0.62 [10,0]
STROKE (IN. [MM])0.56 [14,3]
TONS AT 10,000 PSI [METRIC TONS AT 700 BAR]4.97 [4,5]
WEIGHT (LBS. [KG])2.20 [1,0]

  • Weight:  2.20 lbs
