SPX FLOW Power Team RLS200 20 Ton Hydraulic Single Acting Low Profile Spring Return Cylinder, 7/16" Stroke
SPX FLOW Power Team RLS200 20 Ton Hydraulic Single Acting Low Profile Spring Return Cylinder, 7/16" Stroke
Order No. SPX-RLS200
List Price: $1,003.00
Price: $958.37
Availability: In Stock

IDEAL FOR CONFINED AREAS FROM 1-5/8” TO 4” CLEARANCE.

  • Cylinder body, piston and gland nut "Power Tech" treated for corrosion and abrasion resistance (see page 8)
  • Standard domed piston rod (5-30 ton) or swivel cap (50-150 ton) minimize effects of off-center loading
  • Unique heavy duty spring provides fast piston return
  • A 9796 3/8" NPTF female half coupler is standard with each cylinder (the RLS50 has a 3/8" coupler which is not angled). Oil ports are 3/8" NPTF.
  • Couplers on all cylinders, except RLS50, are angled upward for extra clearance

Specifications

RETRACTED HEIGHT (IN. [MM])2.00 [50,8]
EXTENDED HEIGHT (IN. [MM])2.44 [61,9]
OUTSIDE DIAMETER (IN. [MM])3.00 [76,2]
OUTSIDE DIAMETER (IN. [MM])4.00 [101,6]
BASE TO PORT (IN. [MM])0.66 [16,7]
PISTON ROD DIAMETER (IN. [MM])1.13 [28,6]
MOUNTING HOLE LOCATION (IN. [MM])0.72 [18,3]
MOUNTING HOLE LOCATION (IN. [MM])1.94 [49,2]
MOUNTING HOLE LOCATION (IN. [MM])0.53 [13,5]
MOUNTING HOLE LOCATION (IN. [MM])1.56 [39,7]
BORE DIAMETER (IN. [MM])2.38 [60,3]
CYLINDER CAPACITY (TONS)20
CYLINDER EFFECTIVE AREA (SQ. IN. [CM²]4.43 [28,6]
INTERNAL PRESSURE AT CAPACITY (PSI)9029
OIL CAPACITY (CU. IN. [CM³])2.00 [33,0]
STROKE (IN. [MM])0.44 [11,1]
TONS AT 10,000 PSI [METRIC TONS AT 700 BAR]22.15 [20,1]
WEIGHT (LBS. [KG])5.60 [2,5]

  • Weight:  5.60 lbs
