SPX FLOW Power Team RLS500S SPX FLOW Power Team RLS500S 50 Ton Hydraulic Single Acting Low Profile Spring Return Cylinder, 5/8" Stroke

SPX FLOW Power Team RLS500S 50 Ton Hydraulic Single Acting Low Profile Spring Return Cylinder, 5/8" Stroke

Order No. SPX-RLS500S

List Price: $1,345.00

Price: $1,285.14

Availability: In Stock

IDEAL FOR CONFINED AREAS FROM 1-5/8” TO 4” CLEARANCE.

Cylinder body, piston and gland nut "Power Tech" treated for corrosion and abrasion resistance (see page 8)
Standard domed piston rod (5-30 ton) or swivel cap (50-150 ton) minimize effects of off-center loading
Unique heavy duty spring provides fast piston return
A 9796 3/8" NPTF female half coupler is standard with each cylinder (the RLS50 has a 3/8" coupler which is not angled). Oil ports are 3/8" NPTF.
Couplers on all cylinders, except RLS50, are angled upward for extra clearance

Specifications

RETRACTED HEIGHT (IN. [MM])	2.63 [66,7]
EXTENDED HEIGHT (IN. [MM])	3.25 [82,6]
OUTSIDE DIAMETER (IN. [MM])	4.50 [114,3]
OUTSIDE DIAMETER (IN. [MM])	5.50 [139,7]
BASE TO PORT (IN. [MM])	0.84 [21,4]
PISTON ROD DIAMETER (IN. [MM])	1.75 [44,5]
MOUNTING HOLE LOCATION (IN. [MM])	0.94 [23,8]
MOUNTING HOLE LOCATION (IN. [MM])	2.63 [66,7]
MOUNTING HOLE LOCATION (IN. [MM])	0.94 [23,8]
MOUNTING HOLE LOCATION (IN. [MM])	2.13 [54,0]
BORE DIAMETER (IN. [MM])	3.50 [88,9]
CYLINDER CAPACITY (TONS)	50
CYLINDER EFFECTIVE AREA (SQ. IN. [CM²]	9.62 [62,1]
INTERNAL PRESSURE AT CAPACITY (PSI)	10394
OIL CAPACITY (CU. IN. [CM³])	6.00 [99,0]
STROKE (IN. [MM])	0.63 [15,9]
TONS AT 10,000 PSI [METRIC TONS AT 700 BAR]	48.10 [43,6]
WEIGHT (LBS. [KG])	14.00 [6,3]
