SPX FLOW Power Team RSS101 10 Ton Hydraulic Single Acting Spring Return Shorty Cylinder, 1.5" Stroke
SPX FLOW Power Team RSS101 10 Ton Hydraulic Single Acting Spring Return Shorty Cylinder, 1.5" Stroke
Order No. SPX-RSS101
List Price: $760.00
Price: $677.78
Availability: In Stock

IDEAL FOR CONFINED AREAS FROM 3-1/2" TO 11-7/16" CLEARANCE.

  • Power Tech plated piston rods and gland nuts resist scoring and corrosion.
  • Heavy duty return spring (except for double acting models) provides fast piston return & low collapsed height.
  • Coupler on 10 thru 50 ton models is angled upward 5° for added clearance.
  • Grooved piston top keeps load from sliding.
  • Cylinders can be "dead-ended" at full capacity.
  • Removable carrying handles on 100 ton and 250 ton models.

Specifications

RETRACTED HEIGHT (IN. [MM])3.50 [88,9]
EXTENDED HEIGHT (IN. [MM])5.00 [127,0]
OUTSIDE DIAMETER (IN. [MM])2.75 [69,9]
BASE TO PORT (IN. [MM])0.63 [15,9]
PISTON ROD DIAMETER (IN. [MM])1.50 [38,1]
BORE DIAMETER (IN. [MM])1.69 [42,9]
CYLINDER CAPACITY (TONS)10
CYLINDER EFFECTIVE AREA - PUSH (SQ. IN. [CM²]2.24 [14,4]
INTERNAL PRESSURE AT CAPACITY - PUSH (PSI)8943
OIL CAPACITY - PUSH (CU. IN. [CM³])3.40 [56,0]
OIL CAPACITY - RETURN (CU. IN. [CM³])–
STROKE (IN. [MM])1.50 [38,1]
TONS AT 10,000 PSI - PUSH [METRIC TONS AT 700 BAR - PUSH]11.20 [10,2]
WEIGHT (LBS. [KG])6.00 [2,7]

  • Weight:  6.00 lbs
